We can supply Pengfei brand rotary kiln (titanium pigment kiln, sintering furnace, industrial furnace, kiln, acid pellet) made by Jiangsu Pengfei Group Co., Ltd. whose specifications are Φ3.2×52m,Φ3.5×54m,dia.4.0×60m,d4.3×64m,Φ4.8×74m and Φ5.0×78m and used for 8000t/d, 5000t/d and 2500t/d new dry basis complete rotary kiln equipments. Pengfei brand rotary kiln is the main equipment for calcining cement clinker and it can be used widely for cement industry, metallurgy industry, chemical industry, etc. The rotary kiln is composed of the shell, the supporting device, the supporting device with thrust roller, the driving device, the movable kiln head, the sealing device at kiln tail, the combustion device, etc. It has the simple structure and reliable operation, at the same the production process of the rotary kiln can be controlled easily.
Through the technical renovations, the rotary kiln calcining system equipment made by Pengfei has adopted the advanced hydraulic thrust roller device, the high measuring precession plunger pump, the variable speed adjusted valve, the contact graphite block sealing device and the other national advanced technologies. In order to raise up automation degree, the industrial TV has been used at the kiln head for monitoring of kiln, the simulation phosphor screen has been used for display of process flow; the infrared scanning system has been adopted for calcining zone to directly reflect the burning conditions on the computer. With the use of these new of these new technologies, it is direct in vision, convenient in operation and reliable in use. Therefore, the thermal condition can be stabilized and the running rate of equipment can be raised. Compared to same sized equipment, its running rate has been raised 10% up, production has been increased 5-10% and heat consumption has been reduced 15% down.
Technical parameter
|
|
Specification(m)
|
φ2.8/2.5×44
|
φ3×48
|
φ3.2×50
|
φ3.3×50
|
φ3.5×54
|
φ4×60
|
φ4.3×64
|
φ4.8×74
|
φ5.0×74
|
φ5.6×87
|
φ6.0×95
|
|
Capacity(t/d)
|
300
|
600-700
|
1000
|
1200
|
1500-1800
|
2500
|
3500
|
5000
|
6000
|
8000
|
10000
|
|
Slope of the kiln shell (%)
|
3.5
|
3.5
|
3.5
|
4
|
4
|
4
|
4
|
4
|
4
|
4
|
4
|
|
No.of supporters
|
3
|
3
|
3
|
3
|
3
|
3
|
3
|
3
|
3
|
3
|
3
|
|
Type of thrust roller
|
Mechanical
|
|
Hydraulic
|
Hydraulic
|
Hydraulic
|
Hydraulic
|
Hydraulic
|
|
Hydraulic
|
Hydraulic
|
Hydraulic
|
|
Rotary speed of kiln
|
Main driving (r/min)
|
0.445-2.22
|
0.676-3.38
|
0.36-3.57
|
0.36-3.57
|
0.39-3.9
|
0.41-4.07
|
0.4-4.0
|
0.35-4
|
0.35-4
|
Max4.23
|
Max5
|
|
Auxiliary driving (r/min)
|
4.75
|
9.36
|
6.5
|
5.61
|
7.66
|
8.2
|
7.93
|
8.52
|
7.58
|
8.7
|
9.2
|
|
|
Motor
|
Type
|
ZSN4-225-21
|
Z2-101
|
ZSN4-280-191B
|
ZSN4-280-191B
|
ZSN4-315-092
|
ZSN4-355-092
|
ZSN4-355-12
|
ZSN4-450-092Lp44
|
ZSN4-450-092
|
ZSN4-450-12
|
ZSN4-500-092
|
|
Rated power(kw)
|
55
|
100
|
160
|
160
|
220
|
315
|
400
|
630
|
710
|
800
|
950×2
|
Seed regulation
Range(r/min)
|
～1000
|
～1500
|
1500
|
1500
|
1000
|
1000
|
100-1000
|
1500
|
87.5～1000
|
100～1000
|
100～1000
|
|
Rated voltage(V)
|
440
|
220
|
440
|
440
|
440
|
440
|
440
|
660
|
600
|
600
|
600
|
|
Reducer
|
Type
|
ZS145-1-1
|
ZS145-1-1
|
ZSY-450-40-V
|
ZSY450-40
|
NZS995-28VIBL
|
YNS1110-22.4VBR
|
YNS1400-3105VIBL
|
JH710C-SW305-40
|
JH280C-45
|
JH900C-SW305-25
|
JH900C-SW305-28
|
|
Total speed ratio
|
49-63
|
50
|
40
|
40
|
28
|
22.4
|
31.5
|
42.226
|
28
|
23.901
|
26.646
|
|
|
|
Type
|
Y122M-4
|
Y160M-6
|
Y160M-4B
|
Y160M-4
|
Y200L1-6
|
Y180L-4
|
Y200L-4
|
Y225M-4 lp44
|
Y250M-4
|
Y280M-4
|
Y315M1-4
|
|
Rated power (kw)
|
4
|
7.5
|
15
|
11
|
18.5
|
22
|
30
|
55
|
55
|
90
|
132
|
Rated rotary
Speed (r/min)
|
1440
|
970
|
1460
|
1460
|
970
|
1470
|
1470
|
1480
|
1480
|
1480
|
1490
|
|
Rated voltage(v)
|
380
|
380
|
380
|
380
|
380
|
380
|
380
|
380
|
380
|
380
|
380
|
|
|
Type
|
ZL35-16
|
ZL35-7-1
|
ZSY160-31.5-‖
|
ZSY355-31.5
|
ZSY355
|
YNS440-45‖R
|
YNS497-45ZC
|
JH220C-SW302-28
|
JH280C-45
|
ZSY400-35.5-︱
|
ZSY450-35.5-︱
|
|
Total speed ratio
|
40.44
|
14
|
31.5
|
31.5
|
45
|
45
|
45
|
28
|
45
|
35.795
|
35.795
|
|
Totalweight (excluding refractory brick)(t)
|
177
|
213
|
280.6
|
317
|
341
|
434
|
562
|
854
|
885
|
1201
|
1580
|
|
|
|
===========================================================================================================================================
Jiangsu Pengfei Group Co., Ltd has the great comprehensive ability to provide the best quality services on turn-key basis with the complete equipment、 the installation and the debugging for the new type dry process rotary kiln cement factories under the daily capacity of 8000ton、5000ton and 2500ton and compound fertilizer plants under the annual capacities of the 300000ton. The “Pengfei” brand rotary kiln cement complete equipment have been sold exported to Russia、 The Kingdom of Denmark、Germany、kazakhstan、Mongolia、Ukraine、Uruguay、uzbekistan、 Bangladesh、Pakistan、Laos、Peru、India and so on . MD export project are X18, X519, Son La, Lang Son, Da Ye, Chai Shai Cement factories in Vietnam, Tiger-Head, King Elephant Cement Plants in the union of MD and so on . All of these cement complete equipment production line have been widely praised by the international friends.
The key words are : Jingsu Pengfei Group、 cement machinery、 cement equipment、 cement machinery equipment、 cement complete equipment、 cement machinery complete equipment、mining equipment、Tube mill、Ball mill、Cement mill、Coal mill、Slag mill、Raw mill、Mining mill、vertical mill、roller press 、grinding equipment. The leading products are the cement machinery equipment such as the “Pengfei” brand rotary kiln、 ball mill、 Tube mill、 Cement mill、Coal mill、Slag mill、Raw mill、Mining mill、cooler、 vertical mill、 roller press、grinding equipment、conditioning tower、dust collector、 shaft mill、rolling machine、drier、crusher and conveyor and so on.
|
